Cable and Antenna Analysis
The Anritsu Site Master is a trusted industry standard for cable and antenna analysis. There are several configurations available. To choose the right configuration, you will need to know the various frequencies you will be working with. One of ourÂ Gear ExpertsÂ can help you out if youâ€™re unsure. What is PIM? PIM, or passive intermodulationÂ is interference generated "when two or more signals transit through a passive device with nonlinear propertiesÂ (Analog Dialogue)."Â PIM can arise in a number of ways: bad or improperly tightened connectors, rusty brackets or other metals, and more. No matter the cause, youâ€™ll need to find the issue and fix it because that frequency interference will potentially result in a carrier losing customers or incurring fines. The PIM Master can analyze a system and provide a Distance-to-PIM reading. The Distance-to-PIM reading will help you narrow in on what is causing any interference, and you can get to work on fixing the issue.
Historically, antenna equipment was supported through COAX cable. With 4G and beyond, a good portion of this COAX cable is being replaced with fiber optic cable to remove interference and increase signal strength. By relying on light rather than electrical charges through COAX, there are fewer variables to interfere with signal strength. That said, thereâ€™s still interference in fiber and youâ€™ll need to keep a few things in mind as you purchase equipment to service fiber optic systems. First, the actual glass fiber in a Singlemode fiber cable is only 62.5 microns wide - about the diameter of a human hair. At such a small size, small particles on connectors or tiny fractures in the glass can cause interference in the strand and weaken its signal strength.Â The majority of the bulk in a fiber optic cable is protective cladding. As light travels through the fiber, itâ€™s constantly hitting impurities that make the light scatter or reflect back. This reflectance decreases the overall strength of the light at its destination. Thatâ€™s why testing and identifying the impurities, scattering, etc., is such an important step to fixing loss within a fiber optic system. The typical measurements tested for these super-thin strands are distance measurements, loss measurements, and reflectance measurements. Anritsu has several tools to help test, inspect, and measure fiber. The Video Inspection Probe, is a fiber microscope that allows you to visually inspect connectors. Light Sources allow you to beam light from one end of a fiber optic cable for a quick light test. With these devices, you can run a fairly simple pass/fail test. If you want to figure out where along the fiber you have a failure, youâ€™ll need an OTDR device. An OTDR, or Optical Time Delay and Reflectometer, allows you to generate the pulses of light to the other end to verify and locate any reflectance. The OTDR ACCESS Master is Anritsuâ€™s standalone OTDR solution. Not only do Anritsu OTDR find and locate reflectance, but they also offer recommendations and advice for solutions to fix any reflectance in the fiber. **The content of this blog is not intended to replace proper, in-depth training. Manufacturerâ€™s instructions must also be followed and reviewed before any equipment is used.
