Type EF Liquidtight Flexible Metal Conduit 1 Inch x 30 Feet
Liquidtight Metal Conduit, Extra Flexible, 4 in, 4 to 4.04 in Inside Dia, 4.46 to 4.5 in Outside Dia, 25 ft Coil Length, 24 in Bend Radius, -10 to 60 deg C, Galvanized Steel, Gray.
Features:
- Smooth metal interior for easy wire pulling
- Requires standard liquid-tight fittings
- Delivers wiring protection where listed products are not required
- For exposed or concealed installations requiring movement, crossover connections, or tight bends
- A flame-retardant, flexible PVC jacket is extruded over the metal core
- Oil, sunlight resistant
- Resistant to weather, heat, oil, and chemical breakdown
- Seals out abrasives, alcohol, coolants, corrosive fumes and gases, dirt, grease, mineral acids, non-concentrated fixed alkalines, petroleum oils, salt air spray, water and weather
- The gray jacket resists oils, mild acids, and exposure to sunlight
- Type EF is manufactured with a spiral wound interlocked strip of corrosion-resistant, galvanized steel
Specifications:
- Color: Gray
- Length: 30 ft
- Size: 1 in
- Material: Steel
- Finish: Hot Dipped Zinc Galvanized
- Type: Liquid-Tight, Metallic
