Super Anchor D-Minus Anchor
The D-Minus anchor is our most economical fall arrest anchor and is available in gray powder coated 11-gauge mild steel or 11-gauge 430 stainless steel. Installs with 6 factory-supplied stainless steel spiral shank nails or optional #12 screws. This anchor is specified for use on asphalt shingle roofing and is low profile making them difficult to notice on the roof. This anchor can be used for new construction, reroofing, or retrofitting onto existing roofs. In addition, this anchor can be used in conjunction with the Retro-Flash system.
Features:
- Extremely cost-effective
- 5 certified pre-engineered fastener options
- Installs with just 6 fasteners
- Fall Indicator stem warns of in-service loading
- Paintable to match any roofing color
- Accepts all 3,600lb gate strength connectors
- Available in gray powder coated 11-gauge mild steel or 11-gauge 430 stainless steel
- Permanent/Temporary/Disposable/Reusable
- Factory butyl flashing strip available
- Recommended Spacing every 12’ o.c.
- Fasteners are covered by overlapping roofing
- OSHA 5,000 pound rated anchor
- 3rd Party-certified testing documents available upon request
- English, Spanish, and French Manuals
Specifications:
- Device: D-single direction fall arrest anchor
- Fall Protection Rating: Fall Arrest and Fall Restraint
- Structure Attachment: Wood structure
- Minimum Breaking: 5,000 pounds
- Connector Hole: 7/8″ diameter
- Material: 11 gauge powder coated steel or 11 gauge 430 Stainless Steel
- Dimensions: 2″ x 9-1/4″
- Maximum User Weight: 310 pounds maximum body weight with shock absorber
- Working Radius: Direction of slope or 30 degrees
- Hardware: Stainless Spiral Shank Nails or Stainless Steel Screws
- OSHA Standard: 1926:502, 1910.66
- ANSI Standard: Z359.1-07 and A10.32-2012
