Hougen HMD905 Magnetic Drill

Name: Hougen HMD905 Magnetic Drill
SKU: C-HO-0905102
Price: 1757.0 USD
Availability: OutOfStock

$1,757.00 to $1,950.00 Sale price: $1,757.00 to $1,950.00 EA (1)

THIS ITEM SHIPS FOR FREE!

Please select an option below

Base Options *

Standard Swivel Base

Hougen's HMD904 Portable Mag Drill is extremely lightweight and powerful, making it the drill of choice for fabrication. The HMD904 drills holes up to 2-1/2" in diameter and 2" deep. Hougen Drills are made for durability, and come complete with a carrying case and one year warranty. Use this magnetic drill with Hougen Annular Cutters and Hougen Cutting Fluid.

Features:

Large 1-1/2" x 2" capacity
Positive slug ejection
Uses 12,000 Cutters and Copperhead Carbide annular cutters which requires no tools for installation or removal
- 12,000 Cutter Kits
Feed handles quickly change from side to side
Lift detector safety system
Rear mounted controls
Add on the Gravity Feed Coolant System (HMD904C)
Carrying case included
One year warranty

Accessories:

HMD905 SPECIFICATIONS
Electrical System		115V, 50/60 Hz - 10A, 1150W

Motor		9A (115V), 250/450 RPM

Diameter		7/16"- 2" (12mm - 50mm)

Depth		2" (50mm)

Cutter/Mount		"12,000-Series" & Copperhead™ Carbide cutters, 3/4" shank

Dimensions		22-13/16" H x 7-11/16" W x 11-3/4" L (579mm H x 195mm W x 299mm L)

Swivel Area		1" W x 3/4" L (25mm W x 19mm L)

Magnet	Base	3-1/8" W x 6-9/16" L (79mm W x 167mm L)
	1" Plate (25mm)	Dead Lift 1750 lb. (794 kg)	Drillpoint Breakaway 995 lb. (452 kg)
	3/8" Plate (9.5mm)	1310 lb. (594 kg)	710 lb. (322 kg)

Magnet (Swivel)	1" Plate (25mm)	Dead Lift 1340 lb. (608 kg)	Drillpoint Breakaway For. 695 lb. (315 kg) Back 835 lb. (379 kg)
	3/8" Plate (9.5mm)	1015 lb. (460 kg)	For. 503 lb. (228 kg) Back 605 (274 kg)

Weight		35 lb. (15.9 kg) • Shipping 52 lb (23.6 kg)
Weight (Swivel)		38 lb. (17.2 kg) • Shipping 55 lb (24.9 kg)

Shipping Dimensions		20 x 9.25 x 28.25" (50.8 x 23.5 x 71.8 cm)
