Home > Anritsu Adapter, DC to 6 GHz

Anritsu Adapter, DC to 6 GHz

Multiple Options Available
Please select an option below
FREE SHIPPING OVER $75!

$85.00


Connector Style *


Anritsu Adapter, DC to 6 GHz

Features:

  • Operational from DC – 6 GHz
  • Robust design for long product life
  • Low Insertion Loss
  • Exceptional PIM performance across cellular or wireless frequency range

Specifications:

  • Male to Female (1091-467-R)
  • Female to Female (1091-465-R)
Frequency VSWR Return Loss (dB) Insertion Loss (dB)
DC - 4 GHz 1.15 Max 23 0.10 Max
4 GHz - 6 GHz 1.20 Max 21 0.15 Max

The Anritsu Adapter, DC to 6 GHz boasts a robust design with exceptional PIM performance across cellular or wireless frequency ranges. They support applications in cellular or wireless, tower or in-building as well as production or laboratory measurements using many of the Anritsu handheld instruments.



C-ASU-1091-465-R
Manufacturer: Anritsu
ASU-1091-465-R
ASU-1091-467-R
