AEA Technology E20/20 Time Domain Reflectometer (TDR)

The AEA Technology E20/20 Time Domain Reflectometer (TDR) is ideal for troubleshooting OSPs. It can be used to test all types of coax, OSP cables, twisted pairs Cat2 to Cat6A and single wires in bundle/harness. The E20/20 TDR stores, recalls, and uploads traces to a PC by name, date, and time. It has a user friendly interface to reduce technician learning curve and training time.This TDR also includes features like Setup Wizard, named Menu keys, and Context Sensitive Help. The E20/20 TDR also has new MicroFault locating for small coax kinks and crushes that might be service affecting, but hard to see on a normal TDR trace. It has larger clearer display fonts and LED indicators for active Function Keys. The E20/20 TDR comes in a variety of connector configurations, has an internal internal Cable List that holds 64 cable types, can be user edited, and modified lists can be uploaded or downloaded to a PC using ETDR PC Vision software.

Features:

• Fault locating for: Opens, shorts, bridged taps, split and resplit pairs, water, chaffing damage, coax crimps and splices, shunt faults, series resistive faults, splitters.  Any impedance or loop resistance affecting fault.
• Micro Fault locating: Two modes designed to pin-point small faults easy to miss on any full TDR trace.  Particularly on long coax cables.
• Stores: 32 Traces and instrument setups. 64 Cable types with their impedance and velocity.
• Help: Both a Setup Wizard for step-by-step guided startups and one-button context sensitive help for all menus and functions.The E20/20 Step TDR is guaranteed to save time and money by quickly and accurately locating even small cable faults and by not chasing cable faults that don't exist.View the applicable data sheet below for more details and key specifications.

E20/20 N TDR with Broadcast Features:

• Connector: N type. Cable List: Broadcast. N-to-BNC Adapter & BNC to Alligator clips test lead
• Included items: Soft Equipment case, Belt case, AC adapter, Vehicle charger, USB cable, N-to-BNC Adapter, BNC-to-Alligator Clips Test Lead, basic guide and quick start guide.

E20/20 F TDR with CATV Features:

• Connectors: F & RJ45. Cable List: CATV, RJ45-to-Telco clips and F-to-Alligator clips test lead
• Included items: Soft Equipment case, Belt case, AC adapter, Vehicle charger, USB cable, F Test Lead with quick disconnect, RJ45-to-Telco Clips (2 pair) Test Leads, F-to-Alligator Clips Test Lead, Coax cable, basic guide and quick start guide.

E20/20 F TDR with TELCO Features:

• Connectors: F & RJ45. Cable List: Telco, RJ45-to-Telco clips and F-to-Alligator clips test lead
• Included items: Soft Equipment case, Belt case, AC adapter, Vehicle charger, USB cable, RJ45-to-Telco Clips (2 pair) Test Leads, F-to-Alligator Clips Test Lead, basic guide and quick start guide.

E20/20 B TDR with VDV/RF Features:

• Connectors: BNC & RJ45. Cable List: VDV/RF, RJ45-to-Telco clips and BNC-to-Alligator clips test lead
• Included items: Soft Equipment case, Belt case, AC adapter, Vehicle charger, USB cable, RJ45-to-Telco Clips (2 pair) Test Leads, BNC-to-Alligator Clips Test Lead, basic guide and quick start guide.

Available Options:

• E20/20 N TDR with Broadcast (6021-5000)
• E20/20 F TDR with CATV (6021-5041)
• E20/20 F TDR with TELCO (6021-5042)
• E20/20 B TDR with VDV/RF (6021-5053)
