Home > Brands > Hubbell Power Systems > AB Chance 1000 lb Capacity Capstan Hoist C3081170

Model#: C3081170

Stock#: HB-C3081170

UPC/GTIN/EIN: 096359015987

AB Chance 1000 lb Capacity Capstan Hoist



This item qualifies for Quick Ship. Quick ship items typically ship out the same day you order them as long as the order is placed before 6pm EST, Monday through Friday. Get it by Dec 08

AB Chance 1000 lb Capacity Capstan Hoist

AB Chance Capstan Cathead Hoists deliver high torque rope-pulling muscle with constant control. The C3081170 AB Chance Capstan 115 Volt, AC Powered Cathead Hoist features include an improved design and a multiple-planetary drive/backstop-clutch assembled on the center shaft of a steel gear case with full-length internal teeth. This capstan winch design handles more rugged jobs, extends service life, and reduces maintenance. Lightweight yet powerful, these portable hoists move many heavyweight tasks and can get into remote or difficult-access sites. The recommended output is 4,000 watts or higher. For generator options, consider the Generac GP Series 6500E Portable Generator or Generac GP Series 6500 Cosense Portable Generator.

Examples: tower erection, raising antennas, hoisting, setting utility poles, pulling wheeled equipment over obstacles, raising transformers (even over fences in back lots), hoisting heavy insulators, stringing and tensioning conductors, pulling cable (indoors and underground), and cell tower construction. Capstan operator effort remains low for typical loads simply by adding wraps on the capstan drum. So little effort is required, any crew member can run the cathead hoist. Control is so accurate, rope and loads can be moved by fractions of an inch. The unit features a unique rope-retaining device that prevents the rope from leaving the drum.


Four 3/8" mounting bolts are furnished with each unit. The mounting flange provides eight 3/8" tapped holes on 5-5/8" bolt circle.


  • Catalog No.: C3081170
  • Weight: 49 lbs.
  • Electric Drive: 115-Volt AC
  • Rope Speed: 40 feet per minute
  • Source: 14 amperes motor current
  • Recommended Output: 4,000 Watts or higher
  • Capacity: 1000-lb. load rating
  • Includes foot control

Also see our truck-ready, swivel-mount kit

View Advisory

View Brochure View Safety Guide

Capacity: 1000 lbs
Country of Manufacture: United States
Industry: Construction
General Industry
Oil & Gas
Rope Access & Rescue
Tower Climbing
Tree Care
Wind Energy
Manufacturer: Hubbell Power Systems
Voltage: 115V AC
Weight: 45.80
